Flexbar 90/150-MR semi automatic rebar shearline
מק"ט: 8761e3c5ba57
Rebar shearline with automated length stop, processing of Ø8mm up to Ø32 or Ø50mm
תיאור מוצר
Active storage rack for rebar with 1 or up to 6 levels
Electrically driven entry conveyor with coated rollers
Hydraulic rebar cutting machine with 90mm or 150mm blade width
Automatic length stop for precise cutting length adjustment
PLC control with touch panel, possibility to set up to 5 different cutting lengths in one cycle
Easy removal of bars after cutting by rolling the bars in the collecting pockets
Possibility to integrate bending table
Easy operation, low maintenance
Capacity ca. 1 - 8 tons per shift
Technical specifications
| Bar diameter | Ø8 | Ø10 | Ø12 | Ø14 | Ø16 | Ø20 | Ø25 | Ø28 | Ø32 | Ø40 | Ø50 |
|---|---|---|---|---|---|---|---|---|---|---|---|
| Flexbar-MR 90 max. number of bars per cut | 10 | 8 | 7 | 6 | 5 | 3 | 2 | 1 | 1 | - | - |
| Flexbar-MR 150 max. number of bars per cut | 15 | 13 | 11 | 9 | 8 | 6 | 4 | 2 | 2 | 1 | 1 |
