Bosch Rexroth M-SED seat solenoid valves

מאפיינים טכניים

field_674d511bd4305

בקש הצעת מחיר

סרטון מוצר

תיאור מוצר

Features

- 3/2 and 4/2 directional Bosch Rexroth poppet valve with solenoid actuation

- Direct operated directional poppet valve with solenoid actuation

- Porting pattern to ISO 4401-05-04-0-05 and NFPA T3.5.1 R2-D05

- Subplates to data sheet RE 45054 (separate order)

- Blocked port is leak-free closed

- Reliable operation also after longer periods of standstill under pressure

- Wet-pin DC solenoids with detachable coil (AC voltage possible with rectifier)

- Solenoid coil can be rotated around 90°

- For changing the coil, the pressure-tight chamber needs not to be opened

- Electrical connection as individual connection

- With concealed manual override, optional

- Inductive position switches and proximity sensors (contactfree and floating), see RE 24830

- For further electrical connections, see RE 08010

Pressure		p max	Bar	350
Capacity		qVmax	l/min	40

Code	Description
R900214841	M-4SED 10 D1X/350CG110N9K4
R900244210	M-4SED 10 D1X/350CG125N9K4
R901203731	M-4SED 10 D1X/350CG24K4
R900205054	M-4SED 10 D1X/350CG24N9K4
R900216007	M-4SED 10 D1X/350CG24N9K4/P
R900059768	M-4SED 10 D1X/350CG96N9K4
R901141383	M-4SED 10 D1X/350CG96N9K4QMAG24/P
R900786951	M-4SED 10 Y1X/350CG110N9K4
R901226305	M-4SED 10 Y1X/350CG220N9K4
R900218878	M-4SED 10 Y1X/350CG24N9K4
R900224654	M-3SED 10 CK1X/350CG110N9K4
R900716870	M-3SED 10 CK1X/350CG110N9K4/B12
R900986815	M-3SED 10 CK1X/350CG110N9K4/V
R900224657	M-3SED 10 CK1X/350CG125N9K4
R900224658	M-3SED 10 CK1X/350CG125N9K4QMAG24
R900204837	M-3SED 10 CK1X/350CG205N9K4
R900224666	M-3SED 10 CK1X/350CG220N9K4
R900224670	M-3SED 10 CK1X/350CG220N9K4QMAG24
R901329228	M-3SED 10 CK1X/350CG220N9K4QMBG24
R900224672	M-3SED 10 CK1X/350CG24K4
R900618582	M-3SED 10 CK1X/350CG24K4QMAG24
R900086685	M-3SED 10 CK1X/350CG24N9K4
R900052510	M-3SED 10 CK1X/350CG24N9K4/B15
R900059317	M-3SED 10 CK1X/350CG24N9K4/B15V
R900224641	M-3SED 10 CK1X/350CG24N9K4/B20
R900219646	M-3SED 10 CK1X/350CG24N9K4/B22
R900223878	M-3SED 10 CK1X/350CG24N9K4/P
R900058244	M-3SED 10 CK1X/350CG24N9K4/V
R900224645	M-3SED 10 CK1X/350CG24N9K4QMAG24
R900224646	M-3SED 10 CK1X/350CG24N9K4QMBG24
R901271163	M-3SED 10 CK1X/350CG24N9XNK4/V
R900053910	M-3SED 10 CK1X/350CG96N9K4
R900224649	M-3SED 10 CK1X/350CG96N9K4/B15
R900058332	M-3SED 10 UK1X/350CG110N9K4
R900740560	M-3SED 10 UK1X/350CG110N9K4/V
R900203464	M-3SED 10 UK1X/350CG125N9K4
R900058331	M-3SED 10 UK1X/350CG205N9K4
R901371995	M-3SED 10 UK1X/350CG220N9K4QMAG24
R900223675	M-3SED 10 UK1X/350CG24K4
R900224682	M-3SED 10 UK1X/350CG24K4QMAG24
R900051053	M-3SED 10 UK1X/350CG24N9K4
R900224685	M-3SED 10 UK1X/350CG24N9K4/B12
R900224294	M-3SED 10 UK1X/350CG24N9K4/B18
R900207002	M-3SED 10 UK1X/350CG24N9K4/B20
R900224689	M-3SED 10 UK1X/350CG24N9K4/B20V
R900243630	M-3SED 10 UK1X/350CG24N9K4/B22
R900213700	M-3SED 10 UK1X/350CG24N9K4/P
R900215488	M-3SED 10 UK1X/350CG24N9K4/V
R900224692	M-3SED 10 UK1X/350CG24N9K4QMAG24/B22
R900224694	M-3SED 10 UK1X/350CG42N9K4
R900218884	M-3SED 10 UK1X/350CG96N9K4
R900224700	M-3SED 10 UK1X/350CG96N9K4/V
R901149907	M-2SED 6 NK1X/350CG110N9K4
R901308618	M-2SED 6 NK1X/350CG24K4QMAG24
R900058247	M-2SED 6 NK1X/350CG24N9K4
R901235712	M-2SED 6 NK1X/350CG24N9K4/B18
R901175783	M-2SED 6 NK1X/350CG24N9K4/V
R900204108	M-2SED 6 NK1X/350CG24N9K4QMAG24
R901259579	M-2SED 6 NK1X/350CG24N9K72L
R900053408	M-2SED 6 NK1X/350CG96N9K4
R901254899	M-2SED 6 PK1X/350CG110N9K4
R901153453	M-2SED 6 PK1X/350CG205N9K4
R900203993	M-2SED 6 PK1X/350CG24N9K4
R900994172	M-2SED 6 PK1X/350CG24N9K4/B12
R900617634	M-2SED 6 PK1X/350CG24N9K4/B15
R901269699	M-2SED 6 PK1X/350CG24N9K4/B15V
R901147471	M-2SED 6 PK1X/350CG24N9K4/B20
R901277963	M-2SED 6 PK1X/350CG24N9K4/B22V
R900058740	M-2SED 6 PK1X/350CG24N9K4QMBG24
R901259598	M-2SED 6 PK1X/350CG24N9K72L
R900247752	M-2SED 6 PK1X/350CG96N9K4
R900058333	M-3SED 6 CK1X/350CG110N9K4
R900224321	M-3SED 6 CK1X/350CG110N9K4/B18
R900224322	M-3SED 6 CK1X/350CG110N9K4QMAG24
R901266454	M-3SED 6 CK1X/350CG110N9XEZ2
R900224328	M-3SED 6 CK1X/350CG125N9K4
R900224329	M-3SED 6 CK1X/350CG125N9K4/B12
R900224494	M-3SED 6 CK1X/350CG205K4
R900223863	M-3SED 6 CK1X/350CG205N9K4
R900224535	M-3SED 6 CK1X/350CG240N9K4
R900083344	M-3SED 6 CK1X/350CG24K4
R901128992	M-3SED 6 CK1X/350CG24K4/B22V
R900987177	M-3SED 6 CK1X/350CG24K4QMAG24
R900052392	M-3SED 6 CK1X/350CG24N9K4
R900224510	M-3SED 6 CK1X/350CG24N9K4/B08
R900224512	M-3SED 6 CK1X/350CG24N9K4/B10
R900200031	M-3SED 6 CK1X/350CG24N9K4/B12
R900224514	M-3SED 6 CK1X/350CG24N9K4/B12V
R900224515	M-3SED 6 CK1X/350CG24N9K4/B15
R900224516	M-3SED 6 CK1X/350CG24N9K4/B15V
R900224517	M-3SED 6 CK1X/350CG24N9K4/B18
R900224520	M-3SED 6 CK1X/350CG24N9K4/B20
R900224522	M-3SED 6 CK1X/350CG24N9K4/B22
R900223864	M-3SED 6 CK1X/350CG24N9K4/P
R900224526	M-3SED 6 CK1X/350CG24N9K4/V
R900214055	M-3SED 6 CK1X/350CG24N9K4QMAG24
R901001627	M-3SED 6 CK1X/350CG24N9K4QMAG24/B12
R900224529	M-3SED 6 CK1X/350CG24N9K4QMBG24
R901011799	M-3SED 6 CK1X/350CG24N9XEZ2
R901235075	M-3SED 6 CK1X/350CG24N9XEZ2/B15V
R901264650	M-3SED 6 CK1X/350CG24N9XNK4
R901271235	M-3SED 6 CK1X/350CG24N9XNK4/B15V
R901271232	M-3SED 6 CK1X/350CG24N9XNK4/V
R900216750	M-3SED 6 CK1X/350CG48N9K4
R900224542	M-3SED 6 CK1X/350CG48N9K4/V
R900218734	M-3SED 6 CK1X/350CG96N9K4
R901039364	M-3SED 6 CK1X/350CG96N9K4/B12V
R901149637	M-3SED 6 CK1X/350CG96N9K4/B15V
R900223866	M-3SED 6 CK1X/350CG96N9K4/P
R900224551	M-3SED 6 CK1X/350CG96N9K4/V
R901053368	M-3SED 6 CK1X/350CG96N9K4QMBG24
R901340760	M-3SED 6 CK1X/350CW110RN9XEZ2/B20
R901270798	M-3SED 6 CK1X/350CW110RN9XEZ2/V
R900224492	M-3SED 6 UK1X/315CG24N9K4=CSA
R900224566	M-3SED 6 UK1X/350CG110N9K4
R900223893	M-3SED 6 UK1X/350CG110N9K4/V
R900223868	M-3SED 6 UK1X/350CG12N9K4
R900223869	M-3SED 6 UK1X/350CG205N9K4
R900223870	M-3SED 6 UK1X/350CG205N9K4/P
R900223676	M-3SED 6 UK1X/350CG24K4
R901088606	M-3SED 6 UK1X/350CG24K4/B08
R900224595	M-3SED 6 UK1X/350CG24K4/B12
R900229943	M-3SED 6 UK1X/350CG24K4/P
R900224598	M-3SED 6 UK1X/350CG24K4QMAG24
R900052621	M-3SED 6 UK1X/350CG24N9K4
R900224603	M-3SED 6 UK1X/350CG24N9K4/B10
R900215709	M-3SED 6 UK1X/350CG24N9K4/B12
R900224606	M-3SED 6 UK1X/350CG24N9K4/B15
R900224609	M-3SED 6 UK1X/350CG24N9K4/B20
R901214172	M-3SED 6 UK1X/350CG24N9K4/B22V
R900208583	M-3SED 6 UK1X/350CG24N9K4/P
R900224613	M-3SED 6 UK1X/350CG24N9K4/PV
R900221358	M-3SED 6 UK1X/350CG24N9K4/V
R900224614	M-3SED 6 UK1X/350CG24N9K4QMAG24
R901321031	M-3SED 6 UK1X/350CG24N9K4QMAG24/B20
R900224616	M-3SED 6 UK1X/350CG24N9K4QMBG24
R901009514	M-3SED 6 UK1X/350CG24N9XEZ2
R900224624	M-3SED 6 UK1X/350CG48N9K4
R901050393	M-3SED 6 UK1X/350CG48N9K4/B20
R900224631	M-3SED 6 UK1X/350CG96K4
R900207848	M-3SED 6 UK1X/350CG96N9K4
R900224632	M-3SED 6 UK1X/350CG96N9K4/B12
R900223871	M-3SED 6 UK1X/350CG96N9K4/P
R900224634	M-3SED 6 UK1X/350CG96N9K4/V
R901199102	M-3SED 6 UK1X/350CG96N9K4QMBG24
R901158746	M-3SED 6 UK1X/350CW110RN9XEZ2/V
R900222505	M-4SED 6 D1X/350CG110N9K4
R900212659	M-4SED 6 D1X/350CG205N9K4
R900058047	M-4SED 6 D1X/350CG24N9K4
R900987651	M-4SED 6 D1X/350CG24N9K4/B10
R900989290	M-4SED 6 D1X/350CG24N9K4/B12
R900616727	M-4SED 6 D1X/350CG24N9K4/B20
R900059471	M-4SED 6 D1X/350CG24N9K4/P
R900737174	M-4SED 6 D1X/350CG24N9K4/V
R901264773	M-4SED 6 D1X/350CG24N9XNK4
R900049890	M-4SED 6 D1X/350CG96N9K4
R900707699	M-4SED 6 Y1X/350CG110N9K4/B15
R900218655	M-4SED 6 Y1X/350CG24N9K4
R900752238	M-4SED 6 Y1X/350CG24N9K4/V
R901264145	M-4SED 6 Y1X/350CG24N9XNK4
