Bosch Rexroth 4WS (E) 2E 10 servo valves
מאפיינים טכניים
field_674d511bd4305
סרטון מוצר
תיאור מוצר
Features
- Nominal size 10
- 5X Series
- Maximum operating pressure 315 bar
- Maximum flow 180 l / min
– Bosch Rexroth valve to control position, force, pressure or velocity
– 2-stage servo valve with mechanical or mechanical and electric return
– 1st stage as nozzle flapper plate amplifier
– Subplate mounting: Porting pattern according to ISO 4401
– Dry control motor, no pollution of the solenoid gaps by the hydraulic fluid
– Can also be used as 3-way version
– Wear-free control spool return element
– Control:
• External control electronics in Eurocard format or in modular design (separate order)
• Or control electronics integrated in the valve (OBE)
– Valve and integrated control electronics are adjusted and tested
– Control spool with flow force compensation
– Control sleeve centrically fixed; thus low susceptibility to temperature and pressure
– Pressure chambers at the control sleeve with gap seal, no wear of the seal ring
– Filter for 1st stage externally accessible
| Grandezza nominale | 10 | |||
| Pressione d'esercizio | p max | bar | 315 | |
| Portata nominale | Δp = 70 bar | q V nom | l/min | 5/10/20/30/45/60/75/90 |
| Isteresi max. | % | ≤ 1,5 % | ||
| R901184572 | 4WSE2ED10-5X/10B13ET315K31EV |
| R901215668 | 4WSE2ED10-5X/10B13T315K31DV |
| R900780250 | 4WSE2ED10-5X/10B9ET315K31EV |
| R900965878 | 4WSE2ED10-5X/20B13T315K31EV |
| R900918001 | 4WSE2ED10-5X/20B9ET315K31EV |
| R901060779 | 4WSE2ED10-5X/20B9T315K31EV |
| R900922137 | 4WSE2ED10-5X/30B13T210K31EV |
| R901128713 | 4WSE2ED10-5X/30B8-315K31EV-121 |
| R900918002 | 4WSE2ED10-5X/30B9ET210K31EV |
| R900918003 | 4WSE2ED10-5X/30B9ET315K31EV |
| R900248928 | 4WSE2ED10-5X/30B9T315K31EV |
| R900909230 | 4WSE2ED10-5X/45B13ET315K31EV |
| R900946935 | 4WSE2ED10-5X/45B13T315K31EV |
| R900921236 | 4WSE2ED10-5X/45B9ET315K31EV |
| R900964209 | 4WSE2ED10-5X/45B9T315K31DV |
| R900715445 | 4WSE2ED10-5X/45B9T315K31EV |
| R901221959 | 4WSE2ED10-5X/5B13T315K31DV |
| R901006219 | 4WSE2ED10-5X/5B9ET315K31EV |
| R900972857 | 4WSE2ED10-5X/60B13-315K31EV |
| R900909228 | 4WSE2ED10-5X/60B13T315K31EV |
| R900707997 | 4WSE2ED10-5X/60B9-315K31EV |
| R900944398 | 4WSE2ED10-5X/60B9ET315K31EV |
| R900909229 | 4WSE2ED10-5X/60B9T315K31EV |
| R900955802 | 4WSE2ED10-5X/75B13-315K31EV |
| R900909225 | 4WSE2ED10-5X/75B13ET315K31EV |
| R901128712 | 4WSE2ED10-5X/75B8-315K31EV-116 |
| R900927674 | 4WSE2ED10-5X/75B9ET315K31EV |
| R900960549 | 4WSE2ED10-5X/75B9T315K31EV |
| R900955905 | 4WSE2ED10-5X/90B13-315K31EV |
| R901126979 | 4WSE2ED10-5X/90B13E315K31EV |
| R901024002 | 4WSE2ED10-5X/90B13T315K31EV |
| R901264153 | 4WSE2ED10-5X/90B9-210K31EV |
| R900918007 | 4WSE2ED10-5X/90B9ET210K31EV |
| R900918008 | 4WSE2ED10-5X/90B9ET315K31EV |
| R900743459 | 4WSE2ED10-5X/90B9T315K31EV |
| R901006216 | 4WSE2EM10-5X/10B9ET315K31EV |
| R900946690 | 4WSE2EM10-5X/20B9ET315K31EV |
| R900949287 | 4WSE2EM10-5X/30B9ET315K31EV |
| R900949288 | 4WSE2EM10-5X/45B9ET315K31EV |
| R901006218 | 4WSE2EM10-5X/5B9ET315K31EV |
| R900914893 | 4WSE2EM10-5X/60B13T315K31EV |
| R901121865 | 4WSE2EM10-5X/60B9ET315K31DV |
| R900946396 | 4WSE2EM10-5X/60B9ET315K31EV |
| R901292434 | 4WSE2EM10-5X/75B13ET315K31DV |
| R900949289 | 4WSE2EM10-5X/75B9ET315K31EV |
| R900968455 | 4WSE2EM10-5X/75B9T315K31EV |
| R900909296 | 4WSE2EM10-5X/90B9ET315K31EV |
