Features

- Bosch Rexroth direct operated high-response valves size 6 and size 10 with control spool and sleeve in servo quality

- Single-side operated, 4/4 fail-safe position in deactivated state

- Integrated digital axis control functionality (IAC-R) for:

- Flow control

- Position control

- Pressure control

- p/Q function

- Substitutional position/pressure and position/ force control

- NC functionality (stand-alone operation possible)

- Analog and digital interfaces for command and actual values

- 4 x analog sensors (+/–10 V or 4..20 mA) or

- 1 x length measurement system (1Vss or SSI) and 2 analog sensors

- Command value provision/actual value response analog (current or voltage) or via field bus

- Analog/digital inputs/outputs configurable

- Field bus connection

- CAN bus with CANopen protocol DS408

- Profibus-DP V0/V1

- Quick commissioning via PC and commissioning software

R901342046	4WRPNH 6 C3 B24L-2X/M/24CA6A-976
R901328704	4WRPNH 6 C3 B40P-2X/M/24PA6B
R901322896	4WRPNH 6 C5 B40L-2X/M/24PF6G
R901298144	4WRPNH 10 C5 B50L-2X/M/24PA6B
R901276197	4WRPNH 10 C5 B50L-2X/M/24PA6A
R901259464	4WRPNH 6 C5 B40P-2X/M/24PF6H
R901239977	4WRPNH 6 C1 B40L-2X/M/24CA6B
R901232767	4WRPNH 10 C5 B100P-2X/M/24PF6G
R901228304	4WRPNH 6 C1B24L-2X/M/24PA6B
R901228303	4WRPNH 10 C1 B100L-2X/M/24PA6B
R901225879	4WRPNH 6 C5 B40L-2X/M/24PA6B
R901224758	4WRPNH 6 C1B24L-2X/M/24PF6G
R901224752	4WRPNH 10 C1 B100L-2X/M/24PF6G
R901211323	4WRPNH 6 C3 B25P-2X/M/24PA6B-561
R901192330	4WRPNH 6 C4 B04L-2X/M/24PF6G
R901189134	4WRPNH 6 C4 B40L-2X/M/24PA6B
R901185512	4WRPNH 6 C3 B40L-2X/M/24FA6B
R901183700	4WRPNH 6 C4 B12L-2X/M/24PA6B
R901182077	4WRPNH 10 C4 B100L-2X/M/24PA6B
R901168217	4WRPNH 6 C3 B02L-2X/M/24PA6B
R901159842	4WRPNH 6 C3 B24L-2X/M/24CA6C
R901140485	4WRPNH 10 C3 B100P-2X/M/24PA6B
R901140101	4WRPNH 6 C3 B25P-2X/M/24PA6A
R901131590	4WRPNH 6 C4 B15P-2X/M/24CA6A
R901125647	4WRPNH 10 C4 B100P-2X/M/24CA6A
R901125645	4WRPNH 10 C3 B100P-2X/M/24CA6A
R901124262	4WRPNH 6 C4 B40P-2X/M/24CA6A
R901100000	4WRPNH 6 C3 B12L-2X/M/24PA6B
R901098487	4WRPNH 6 C3 B04P-2X/M/24PA6B
R901098089	4WRPNH 10 C3 B50L-2X/M/24PA6B
0811403575	4WRPNH 6 C3 B40L-2X/M/24PA6B
0811403573	4WRPNH 6 C3 B25P-2X/M/24PA6B
0811403570	4WRPNH 6 C5 B40P-2X/M/24PA6C
0811403568	4WRPNH 6 C4 B24L-2X/M/24PA6A
0811403565	4WRPNH 6 C4 B25P-2X/M/24CA6A
0811403564	4WRPNH 6 C4 B25P-2X/M/24PA6B
0811403559	4WRPNH 6 C3 B04L-2X/M/24PF6G
0811403554	4WRPNH 6 C3 B40P-2X/M/24PA6C
0811403550	4WRPNH 6 C3 B40L-2X/M/24PA6A
0811403549	4WRPNH 6 C3 B12L-2X/M/24PA6A
0811403545	4WRPNH 6 C4 B40L-2X/M/24PA6A
0811403544	4WRPNH 6 C4 B40L-2X/M/24PF6G
0811403543	4WRPNH 6 C3 B24L-2X/M/24CA6A
0811403542	4WRPNH 6 C3 B40L-2X/M/24CA6A
0811403537	4WRPNH 6 C3 B12L-2X/M/24CF6G
0811403536	4WRPNH 6 C3 B15P-2X/M/24PA6C
0811403535	4WRPNH 6 C4 B12L-2X/M/24PF6G
0811403534	4WRPNH 6 C3 B24L-2X/M/24PA6A
0811403533	4WRPNH 6 C4 B24L-2X/M/24CA6A
0811403532	4WRPNH 6 C4 B24L-2X/M/24PF6G
0811403531	4WRPNH 6 C3 B40L-2X/M/24PF6G
0811403367	4WRPNH 10 C4 B50L-2X/M/24CA6A
0811403364	4WRPNH 10 C3 B100L-2X/M/24PA6A
0811403363	4WRPNH 10 C3 B50L-2X/M/24PA6A
0811403361	4WRPNH 10 C3 B100L-2X/M/24CA6A
0811403359	4WRPNH 10 C4 B100L-2X/M/24PF6G
0811403358	4WRPNH 10 C3 B100L-2X/M/24PF6G
R901335061	4WRPNH 6 C3 B40P-2X/M/24FA6B
R901237536	4WRPNH 10 C3 B100L-2X/M/24FA6B
R901185512	4WRPNH 6 C3 B40L-2X/M/24FA6B
