A2FO Bosch Rexroth pumps

A2FO Bosch Rexroth pumps

מק"ט: 8b85a11570df

מאפיינים טכניים

field_674d511bd4305
בקש הצעת מחיר

סרטון מוצר

תיאור מוצר

The A2FO is a fixed displacement pump with conical piston mechanism in an inclined cylinder block version for hydrostatic drives in open circuit. The flow rate is proportional to the rotation speed and the displacement. Size 5 ... 1000
  • Nominal pressure up to 400 bar
  • Maximum pressure up to 450 bar
  • Open circuit
  • Axial conical pistons with inclined cylinder block
  • Service port SAE flange or thread
  • High power density
  • small size
  • high total return
  • economic efficiency
Grandezza nominale 5 10 12 16 23 28 32 45
Cilindrata V g cm³ 4,93 10,3 12 16 22,9 28,1 32 45,6
Numero di giri nnom min-1 5600 3150 3150 3150 2500 2500 2500 2240
Portata volumetrica a nnom qV l/min 27,6 32,4 37,8 50 57 70 80 102
Potenza Δp = 315 bar P kW 14,5 - - - - - - -
Δ p = 400 bar P kW - 21,6 25 34 38 47 53 68
Coppia Δp = 315 bar T Nm 24,7 - - - - - - -
Δ p = 400 bar T Nm - 65 76 101 145 178 203 290
Massa (ca.) m kg 2,5 6 6 6 9,5 9,5 9,5 13,5
Grandezza nominale 56 63 80 90 107 125 160 180
Cilindrata V g cm³ 56,1 63 80,4 90 106,7 125 160,4 180
Numero di giri nnom min-1 2000 2000 1800 1800 1600 1600 1450 1450
Portata volumetrica a nnom qV l/min 112 126 144 162 170 200 232 261
Potenza Δ p = 400 bar P kW 75 84 96 108 114 133 155 174
Coppia Δ p = 400 bar T Nm 356 400 511 572 678 795 1020 1145
Massa (ca.) m kg 18 18 23 23 32 32 45 45
Grandezza nominale 200 250 355 500 710 1000
Cilindrata V g cm³ 200 250 355 500 710 1000
Numero di giri nnom min-1 1550 1500 1320 1200 1200 950
Portata volumetrica a nnom qV l/min 310 375 469 600 826 950
Potenza Δ p = 350 bar P kW - 219 273 350 497 554
Δ p = 400 bar P kW 207 - - - - -
Coppia Δ p = 350 bar T Nm - 1393 1978 2785 3955 5570
Δ p = 400 bar T Nm 1272 - - - - -
Massa (ca.) m kg 66 73 110 155 322 336

A2FO80/61R-PZB05
R902137715 A2FO125/61R-PAB05
R902137761 A2FO107/61R-PZB05
R902137765 A2FO107/61R-PPB05
R902137814 A2FO80/61R-PPB05
R902137935 A2FO107/61R-PAB05
R902137957 A2FO80/61R-PAB05
R902138020 A2FO107/61R-PBB05
R902138190 A2FO125/61R-PBB05
R902138453 A2FO107/61R-VBB05
R902155654 A2FO200/63R-VAB05
R902155917 A2FO200/63R-VBB05
R902155958 A2FO23/61R-PPB05
R902158545 A2FO10/61L-XAB06-S
R902160050 A2FO63/61L-PAB05
R902160054 A2FO63/61R-PAB05
R902160062 A2FO63/61L-VBB05
R902160525 A2FO63/61L-PBB05
R902160640 A2FO63/61R-PBB05
R902160691 A2FO56/61R-PPB05
R902160732 A2FO56/61R-PAB05
R902160801 A2FO56/61R-PBB05
R902160958 A2FO80/61R-PBB05
R902161005 A2FO63/61R-VBB05
R902161009 A2FO16/61L-PBB06
R902161140 A2FO56/61R-VPB05
R902161281 A2FO45/61L-PAB05
R902161287 A2FO12/61R-PAB06
R902161309 A2FO160/61R-PPB05
R902161334 A2FO63/61L-PAB05
R902193114 A2FO80/61L-PBB05
R902193324 A2FO16/61R-VBB06
R902193341 A2FO23/61R-PZB06-S
R902193356 A2FO32/61L-PBB05
R902193358 A2FO23/61L-PZB05
R902193359 A2FO23/61L-PPB05
R902193365 A2FO12/61R-PPB06
R902193366 A2FO10/61R-PBB06
R902193367 A2FO23/61R-PZB06-S
R902193368 A2FO12/61R-PZB06
R902193369 A2FO28/61R-PPB05
R902193371 A2FO16/61R-VAB06
R902193373 A2FO12/61L-PZB06
R902193385 A2FO16/61L-PAB06
R902193387 A2FO45/61R-PPB05
R902193492 A2FO32/61L-PAB05
R902193495 A2FO32/61R-PAB05-S
R902193496 A2FO45/61R-PZB05-S
R902193498 A2FO160/61R-VBB05-S
R902193524 A2FO32/61R-PBB05-S
R902193574 A2FO45/61R-VPB05
R902193575 A2FO28/61R-VAB05
R902193711 A2FO160/61R-VPB05
R902193740 A2FO23/61L-PAB05
R902193748 A2FO12/61R-PBB06
R902193750 A2FO12/61L-PZB06-S
R902193780 A2FO28/61R-PBB05-S
R902193820 A2FO16/61R-PAB06
R902193857 A2FO160/61L-PPB05-S
R902193864 A2FO180/61R-PBB05-S
R902196958 A2FO80/61R-VPB05
R902197505 A2FO32/61R-VBB05
R902197510 A2FO180/61R-VBB05
R902197512 A2FO16/61R-PBB06-S
R902197514 A2FO45/61R-PAB05-S
R902197544 A2FO16/61L-VAB06
R902197546 A2FO16/61R-XABXX-S
R902197547 A2FO200/63L-VAB05
R902197550 A2FO23/61R-PBB05-S
R902197595 A2FO80/61R-VBB05
R902197607 A2FO180/61R-PBB05-S
R902197619 A2FO28/61L-VPB05
R902197631 A2FO160/61R-VBB05
R902197677 A2FO63/61R-VBB05
R902197711 A2FO28/61R-VBB05
R902197748 A2FO10/61R-VPB06
R902197802 A2FO10/61R-PAB06-S
R902197803 A2FO16/61R-VBB06
R902197878 A2FO10/61R-PPB06-S
R902197927 A2FO12/61R-VPB06
R902197974 A2FO10/61L-PPB06-S
R902198079 A2FO45/61R-VZB05
R902198102 A2FO10/61L-XAB06-S
R902198121 A2FO28/61L-PZB06-S
R902198149 A2FO16/61L-PAB06-S
R902198184 A2FO180/61R-PAB05-S
R902198198 A2FO12/61L-PAB06-S
R902198253 A2FO10/61L-VBB06
R902198291 A2FO12/61R-VBB06
R902198329 A2FO56/61L-VAB05
R902198336 A2FO23/61L-PZB06-S
R902198402 A2FO23/61R-VBB05
R902201506 A2FO28/61R-PPB06-S
R902201594 A2FO160/61L-VPB05
R902201632 A2FO160/61L-PAB05-S
R902201633 A2FO32/61R-VAB05
R902201696 A2FO16/61L-PAB06-S
R902201838 A2FO12/61L-PPB06-S
R902201898 A2FO28/61R-VPB05
R902201899 A2FO180/61L-VBB05
R902201924 A2FO23/61L-PAB05-S
R902203110 A2FO28/61R-PZB06-S
R902203116 A2FO16/61R-PABXX-S
R902203156 A2FO23/61R-PZB05-S
R902203157 A2FO32/61L-PAB05-S
R902203208 A2FO32/61R-XABXX-S
R902204620 A2FO45/61L-PPB05-S
R902205943 A2FO23/61R-PPB06
R902207184 A2FO160/61R-VAB05
R902207292 A4VTG71EP4/32L+A2FO10/61L
R902208527 A2FO10/61L-VAB06
R902208732 A2FO56/61L-VZB05
R902208798 A2FO23/61R-VZB05
R902208799 A2FO28/61R-VZB05
R902208823 A2FO56/61L-VAB05
R902211835 A2FO28/61L-VZB05
R902217606 A2FO80/61L-VZB05
R902217679 A11VLO130LRDH1/10R+A2FO32/61R
R902217871 A2FO5/60L-PCB07-S
R902217993 A2FO200/63R-VBB05
R902217997 A2FO28/61L-PAB05.
R902222071 A2FO12/61R-PPB06
R902222227 A2FO45/61L-VPB05
R902222432 A2FO23/61R-PZB06-S
R902226008 A2FO80/61R-PPB05
R902230046 A2FO10/61R-VAB06 *GO2EU*
R902230047 A2FO107/61R-PPB05 *GO2EU*
R902230048 A2FO12/61R-VAB06 *GO2EU*
R902230049 A2FO125/61R-VBB05 *GO2EU*
R902230050 A2FO16/61R-VAB06 *GO2EU*
R902230051 A2FO160/61R-VPB05 *GO2EU*
R902230052 A2FO180/61R-VBB05 *GO2EU*
R902230053 A2FO200/63R-VBB05 *GO2EU*
R902230054 A2FO28/61R-VPB05 *GO2EU*
R902230055 A2FO28/61R-VAB05 *GO2EU*
R902230056 A2FO32/61R-VAB05 *GO2EU*
R902230057 A2FO32/61R-VBB05 *GO2EU*
R902230058 A2FO45/61R-VPB05 *GO2EU*
R902230059 A2FO56/61R-PPB05 *GO2EU*
R902230060 A2FO56/61R-VAB05 *GO2EU*
R902230061 A2FO63/61R-VBB05 *GO2EU*
R902230062 A2FO63/61R-VAB05 *GO2EU*
R902230063 A2FO80/61R-VPB05 *GO2EU*
R902230064 A2FO80/61R-VAB05 *GO2EU*
R902230065 A2FO90/61R-VBB05 *GO2EU*
R902231253 A2FO28/61R-PPB05
R902233320 A2FO180/61R-VAB05
R902233635 A2FO5/60R-VBB07
R902235201 A2FO28/61R-PZB06
R902237256 A2FO23/61R-VAB05
R902237388 A2FO63/61L-VAB05
R902408403 A A2F O 500 /60R-VPH11
R902408638 A A2F O 250 /60R-VPB05
R902408639 TW A2F O 250 /60R-VP
R902410672 A A2F O 355 /60R-VZH11 -SO 47
R902410674 A A2F O 355 /60L-VZH11 -SO 47
R902411288 A A2F O 355 /60L-VZH11
R902412492 A A2F O 250 /60R-VZB05
R902413835 A A2F O 355 /60R-VPH11
R909409745 A2FO56/61R-PPB05-S
R909427604 A2FO12/61R-VZB06
R987062012 A2FO 250/60L-VPB05
R987062028 A2FO 12/61L-PZB060 (A2FO 12/61L-PZB06)
R987062116 A2FO 200/63R-NBB050 (A2FO 200/63R-NBB05)
R987062124 A2FO 107/61L-VPB050 (A2FO 107/61L-VPB05)
R987063133 A2FO 32/61R-VAB05
R987330160 A2FO125/61L-VAB05
